1-23
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-02
Chapter 1 Overview
Management Options
Cisco RPS Connector
The RPS is a 300W redundant power system that can support six external network
devices and provides DC power to one failed device at a time. It automatically
senses when the internal power supply of a connected device fails and provides
power to that device, preventing loss of network traffic.
Warning
Attach only the Cisco RPS 300 (model PWR300-AC-RPS-N1) to the RPS
receptacle.
For more information about the Cisco RPS 300, refer to the Cisco RPS 300
Redundant Power System Hardware Installation Guide.
Console Port
You can connect a switch to a PC through the console port and the supplied
rollover cable and DB-9 adapter. If you want to connect a switch to a terminal,
you need to provide an RJ-45-to-DB-25 female DTE adapter. You can order a kit
(part number ACS-DSBUASYN=) with that adapter from Cisco. For console-port
and adapter-pinout information, see the “Cable and Adapter Specifications”
section on page B-6.
Management Options
Catalyst 2950 switches offer these management options:
• Cluster Management Suite (CMS)
CMS is made up of three web-based applications that you use to manage
switches. You can use Cluster Builder, which includes Cluster View, and
Cluster Manager to create, configure, and monitor switch clusters. You can
also use Device Manager to manage individual and standalone switches. For
more information, refer to the Catalyst 2950 Desktop Switch Software
Configuration Guide and the CMS online help.
