Operator's Manual - Encore S20/L20 Page -29-
Clarke
®
Encore S20 / L20
Final Assembly Parts List 3/06
Ref # Part No. Description
1 Page 30 Tank Asm., Recovery Ref. Ref.
2 Page 32 Tank Asm., Solution Ref. Ref.
3 Pg 58, 66 Cover Asm., Electrical Ref. Ref.
4 Pg 56, 64 Panel Asm., Rear Ref. Ref.
5 980651 Washer, Flat,
5
/16 88
6 980652 Washer, Lock,
5
/16 99
7 85811A Screw,
5
/16-18 x
3
/4 99
8 Page 34 Lift Asm., Squeegee Ref. Ref.
9 Pg 35, 36 Squeegee Asm. Ref. Ref.
10 980210 Washer, Impeller 1 1
11 980679 Washer, Spacer,
3
/16 x 1½ x
1
/8 11
12 20308A Adaptor, Motor 1 1
13 85727A Screw,
3
/8-16 x 1.0 4 4
15 Page 37 Transaxle Asm. Ref. -
Page 38 Axle Asm. - Ref.
16 980638 Washer, Lock,
3
/8 44
17 Page 39 Lift Asm., Brush Ref. Ref.
18 44809B Motor, Brush 1 1
19 41601A Connector 2 2
20 41602A Housing, Connector 2 2
21 Page 40 Housing Asm., Brush Ref. Ref.
22 32403B Cover, Front 1 1
23 36902A Pins, Nylon 2 2
25 80256A Rivet, Plastic Anchor 1 1
26 80255A Washer, Nylon 1 1
27 699292 Wire Tie 2 2
28 85518A Screw 6 6
29 47202A Suppressor 1 1
30 915102 Key, Shaft 1 1
NI Page 27 Brush or Pad Drivers 1 1
NI 41211A Cable Asm., Battery 1 1
NI 41206A Cable Series 1 1
NI 38720A Spacer, Battery Front 1 1
NI 38721A Spacer, Battery Side 1 1
NOTE: For battery placement and connections see page 10.
NOTE:  indicates a change has been made since the last
publication of this manual.
Qty.
L20
Qty.
S20
