Clarke Encore S20 User Manual

Page -38- Clarke
®
Operator's Manual -Encore S20/L20
Clarke
®
Encore S20
Frame Assembly Drawing and Parts List 8/04
Ref # Part No. Description Qty.
1 63431A Frame Weldment 1
2 87607A Washer, Nylon 1
4 85811A Screw,
5
/16-18 x
3
/4 7
5 85727A Screw,
3
/8-16 x 1 3
6 85836A Screw,
3
/8-16 x 2 1
7 87031A Washer, Flat,
3
/8, SS 8
8 920110 Nut,
5
/16-18 ESNA 7
9 87616A Washer 4
10 61436B* Wheel, Non-Traverse 2
11 60535A Axle,Non-Traverse 1
12 57423A Ring, Retainer 2
* Used on machines built after 8/26/04 starting with
serial #BHXXXX
Ref # Part No. Description Qty.
13 81105A Nut,
3
/8-16 ESNA 4
14 962620 Screw, Hex,
5
/16-24 x
3
/4 2
15 980652 Washer, Lock,
5
/16 2
16 980205 Washer 2
17 61675A Caster 1
18 61252A Bracket, Squeegee 1
19 61433A Nut, Spacer 1
20 85391A Screw,
1
/4-20 x
5
/8 1
21 608210 Spacer, Bolt 1
22 51516A Bushing 1
23 980651 Washer, Flat, Plated,
5
/16 4
24 81112A Nut,
5
/16 ESNA Thin SS 1
25 85814A Screw,
5
/16 -18 x 1¼ 1
4
20
22
21
1
2
4
5
7
19
24
18
6
5
7
7
8
25
4
12
9
16
15
14
10
13
7
11
17
8
7
13
10
14
15
16
9
12
23
