Operator's Manual - Encore S20/L20 Page -33-
Clarke
®
Encore S20/L20
Solution Tank Assembly Parts List 8/04
Ref # Part No. Description L20 S20
1 752020 Clamp 1 1
2 30442A Hose, Drain 1 1
3 832002 Clamp 1 1
4 839401 Valve, Drain 1 1
5 833407 Gasket, Drain 1 1
6 833901 Drain Valve Handle 1 1
7 962987 Screw, 10-24 x
3
/8 11
8 52206A Chain 1 1
9 962943 Screw, 8-18 x ½ PN 1 1
10 30250A Tank, Solution 1 1
11 64517A Hinge, Solution/Recovery 1 1
12 85398A Screw, ¼-20 x
5
/8 44
13 55162A Hosebarb 1 1
14 50248A Clamp, Hose 6 6
15 39335A Hose, 17’ 1 1
16 59612A Valve, Drain, Battery 1 1
17 59610A Valve, Flow, Electric 1 -
21 30172A Hose, Braided, .375 ID x 16½” 1 1
22 51204A Valve, Solution 1 1
23 52414A Connector Straight Hose/Tank 2 2
24 51518A Bushing 2 2
25 84237A Screw, 10-32 x ½ 1 1
26 782002 Clamp 1 1
27 85702A Screw, ¼-20 x 1
3
/4 -1
28 832102 Clamp - 1
29 962798 Screw 10-24-½ - 2
30 820823 Bracket - 1
31 53618A
3
/8 x
3
/8 NPT Hosebarb - 2
32 39337A Hose 2½" - 1
33 51526A Hosebarb, Elbow - 1
34 81110A Nut, 10-24 - 2
35 81104A Nut, ¼-20 ESNA - 1
36 849401 Valve - 1
37 678215 Spacer - 1
38 53619A
3
/8 x ¼ NPT Hosebarb 1 -
39 11703A Solution Cable - ref.
41 35138A Hose, Solution 1 1
42 53562A Filter, Bowl 1 1
NI 839410 Valve Asm. - -
(includes Item #4, 5, 6, 8, 9)
NI 39332A Bulk 100 ft. of hose per P/N
39335A and 39337A
NI 50389A Plunger - -
NI 50390A Spring - -
NI 50391A Diaphragm - -
53562A Components
Clarke P/N Description Qty.
50081A Bowl, Filter 1
53563A Filter, Screen 1
53564A Upper Body 1
54369A Gasket, Bowl 1
