Clarke
®
Operator's Manual - Encore S20/L20 Page -9-
Machine Controls and Features
Squeegee Lift Handle, See Figures 5
The squeegee lift handle is located below the control
handles in the center. It is used to raise or lower the
squeegee. The vac motor is turned on when the
handle is lowered to either the first or last position.
NOTE: Squeegee must be raised to at least the
first position when the machine is backed up.
Float Shut Off, See Figure 6
The shut-off switch for the vac motor is located in the
recovery tank. It automatically turns off the vac motor
when the recovery tank is full. NOTE: If excessive
foaming in recovery tank, defoamer must be
added. Damage to vacuum motor could result
from foam.
Parking Brake, See Figures 7a and 7b (Optional)
The parking brake prevents movement of the machine.
It is located at the rear lower left side of the machine.
To engage the brake, push the pedal down (Figure 7a).
To release the brake, lift pedal up (Figure 7b).
CAUTION: Do not activate the brake while the
machine is moving.
Figure 6
Figure 7a
Figure 7b
Figure 4
Figure 5
