Operator's Manual - Encore S20/L20 Page -57-
Clarke
®
Encore S20/L20
Rear Panel Assembly Parts List 7/02
Ref # Part No. Description
1 68787A Panel, Rear 1 1
2 878514 Solenoid, Vac 1 1
3 81104A Nut, ¼-20 9 9
4 962798 Screw 4 0
5 41150B Control, Speed 1 0
6 41810A Solenoid, Brush 1 1
7 64490A Handle 2 2
8 68789A Lift , Brush 1 1
9 64231A Plate, Wear, Lift, Brush 1 1
10 980603 Washer 4 4
11 962546 Screw, 10-24 x ½ 4 4
12 49765A Harness, Power L20 1 -
49766A Harness, Power S20 - 1
13 85601A Screw, 6-32 x 1¼ PN 4 4
14 47388A Switch 2 2
15 920056 Nut, 6-32 6 6
16 85389A Screw,
3
/8-16 x
5
/8 22
17 980666 Washer, Starlock,
3
/8 22
18 68643A Plate, Wear, Vac 1 1
19 920346 Nut, Pal 1 1
20 61260A Squeegee Lift Plate 1 1
21 64901A Handle, Lift, Squeegee 1 1
22 980692 Washer, Flat,
5
/16 SS 4 4
23 438360 Spring 2 2
24 80028A Bolt, Shoulder,
5
/16 x 1.0 2 2
25 87026A Washer, Flat, ¼ 2 2
26 83302A Stud 1 1
27 854849 Insulator 1 1
28 962212 Screw, 6-32 x
7
/8 22
29 41146A Panel Power Harness 1 1
30 60676A Bracket, Connector, Power 1 1
31 61677A Cable, Lift, Squeegee 1 1
32 54606A Grommet, Slotted, 7.75” 3 3
33 170915 Screw, ¼-20 x
3
/4 Hex 10 10
34 980657 Washer, Lock, ¼ 5 5
35 69858A Latch, Tank, Recovery 1 1
36 81110A Nut, 10-24 ESNA 4 -
37 64498A Handle, Lift, Brush 1 1
38 85391A Screw, ¼-20 x
5
/8 22
39 85395A Screw, ¼-20 x ½ 1 1
40 77093A Label 1 1
41 77092A Label 1 1
42 70302A Label, Battery Install 1 1
43 77233A Label, CE 1 1
44 81217A Nut, ¼-20 x .218H Nylock 2 2
45 70078A Label, Traverse Troubleshooter 1 -
Qty.
L20
Qty.
S20
(for machines with a 41150B traverse controller)
