Clarke
®
Operator's Manual - Encore S20/L20 Page -31-
Clarke
®
Encore S20/L20
Recovery Tank Assembly Parts List 7/02
Drawing #18114A
Ref # Part No. Description Qty.
1 36209A Lid 1
2 962798 Screw, 10-24 x ½ Pan 1
3 34256A Gasket, Lid 1
4 837304 O-Ring 2
5 58069A Strainer 1
6 39336B Tube, Stand 1
7 59877A Seal, Washer 1
8 56459A Relief, Strain 1
9 10660A Switch, Float Kit
(includes #'s 7,25,26)
1
10 32401B Lid, Fill, Solution 1
11 30251A Tank, Recovery 1
12 30132A Tube, Stand 1
13 752020 Clamp, Hose 2
14 824103 Hose, Squeegee 1
15 30443A Hose, Drain 1
16 832002 Clamp 1
17 839401 Valve, Drain 1
18 65503A Latch, Recovery 1
19 833407 Gasket, Drain 1
20 833901 Drain Valve Handle 1
21 962943 Screw, 8-18 x ½ PN 1
22 52206A Chain 1
23 962987 Screw, 10-24 x
3
/8 Pan 1
24 674110 Hose 1
25 41809A Contact 4
26 43402A Housing, Connector 2
27 920797 Nut 1
28 872010 Clamp, Hose 1
29 43401A Housing, Vac Motor Connector 2
30 962986 Screw,
5
/16-18 x
3
/4 1
31 87621A Washer, Shoulder Nylon 1
32 85728A Screw, ¼-20 x 4 Hex 3
33 87026A Washer, Flat, ¼ 3
34 44917A Motor, Vac 1
35 643418 Gasket 1
36 58533A Spacer 3
37 82100A Nut, Lock 1
38 81110A Nut, 10-24 ESNA 1
39 85519A Screw 1
40 692409 Chain, Cover 1
41 47202A Suppressor 1
42 699202 Wire Tie 2
NI 839410 Valve Asm. 1
(includes Item#17,19, 20, 21, 22)
To Next Page
