Clarke
®
Operator's Manual - Encore S20/L20 Page -5-
SPECIFICATIONS:
Model Encore L20 - 00880A Encore S20 00890A
Motor, Vac ¾ HP three stage
tangential discharge
21 Amp
Power Supply 24 volt direct current
(2) 12 Volt 195AH Batteries
Solution Tank 14 gallons 53 Liters
Recovery Tank 14 gallons 53 Liters
Parabolic Squeegee 32" Hard, 34" Flex 81 cm Hard, 86 cm Flex
Motor, Brush .75 hp PM 33 amp
Motor Traction .5 hp PM (.37kw) 23 Amp N/A .5 hp PM (.37kw) 23 Amp NA
Brushes 20 inch 51 cm
Brush Speed 200 rpm
Brush Pressure 100 lbs. 45.36 kg
Speed, Forward 0=250 ft/min. brush assist. 0=76.2 m/min. brush assist
Speed Reverse 0=190 ft/min. N/A 0=58 m/min. NA
Drive Wheels 8" x 2" Neoprene thread 20.32 cm s 5.08cm Neoprene thread
Charger 24V, 25A, 115V/60hz
Length 52½" 133.4 cm
Width (over brush housing) 22¼" 56.5 cm
Height 43½" 110.5 cm
Sound Level (DBA) 74, at 5 feet 74,at 1.5 meters
Cleaning Swath 20 inch 51 cm
Grade Cleaning 5° Incline
Weight 468 lbs. w/(2) 871334A batteries 212.28 kg w(2) 871334A batteries
Shipping Weight 607 lbs. w/wet batteries 275.33 kg w/wet batteries
Battery Weight (each) 113 lbs. (871334A) and 81 lbs. (871335A) 51.26 kg (871334A) and 36.74 kg (871335A)
Shipping Dimensions 28" x 65.5" x 46.5" 71.12 cm x 166.37 cm x 118.11 cm
Introduction & Machine Specifications
Introduction & Machine Specifications
Clarke’s newly designed Encore S20 and L20 automatic scrubbers are efficient and superior floor
cleaning machines. The Encore uses one brush to scrub a path 20 inches wide. A squeegee wipes
the floor while the vacuum motor removes the dirty solution from the floor - all in one pass.
The Encore S20 and L20 automatic scrubbers come complete with two - 12 volt batteries, one battery
charger, either a scrub brush or a pad driver, and one operator’s manual.
Encore L20 w/brake Encore S20 w/brake
00880E 00890E
