Operator's Manual - Encore S20/L20 Page -39-
Clarke
®
Encore S20/L20
Brush Lift Assembly Drawing and Parts List 2/04
Drawing #11446A
Ref # Part No. Description Qty.
1
ref 37, pg 57,65 Handle, Lift, Brush -
2 81104A Nut, ¼-20 ESNA 4
3 848508 Swivel, Rod, Brake 2
4 80042A Screw, Eye, Adjustment 2
5 58691A Spring, Pressure, Sander 1
6 87620A Washer, Shoulder, 8
7 80041A Bolt, Shoulder,
3
/8 x ½ 3
8 87618A Washer 6
9 920181 Nut,
5
/16, ESNA 4
10 63432A Frame, Brush Lift 1
11 80040A Bolt, Shoulder,
3
/8 x
3
/8 2
12 980692 Washer 1
Ref # Part No. Description Qty.
13 69861A Bracket, Motor, Brush 1
14 56493A Spring 1
1551526A Hosebarb 1
16 59610A Valve, Solution Ref
17 85391A Screw, ¼-20 x 2
18 87619A Washer, 375032 1
19 60207A Link, Brush Lift 1
20 87621A Washer, 3001 2
21 81112A Nut,
5
/16-18 Thin ESNA SS 3
22 962798 Screw 10-24 x ½ 2
23 81110A Nut 10-24 2
24 64239A Plate, Deflector 1
25 608210 Spacers (optional)
26 962554 Screw 2
1
2
3
4
5
6
7
8
9
10
11
8
6
29
2
23
21
13
24
22
3
4
14
15
16
17
6
18
6
9
21
12
20
See main frame
assembly
17
19
25
26
