ClimateMaster MPC User Manual

THE SMART SOLUTION FOR ENERGY EFFICIENCY
MPC MultiProtoCol DDC Controls
November 19, 2018
31
(Read Left to Right Across Spread)
Point Name Type Number
Read/Write
Type Register Type ID NV Name Default Gen 3 Gen 4 Gen 5 Gen 6 Gen 7 Description
BACNet ModBus N2 LON
Alarm State BV 1 R DI 10001 BI 1 nvoAlarmState NA X X X X X "ON" indicates a lockout condition exists, "OFF" indicates normal operation.
C1 Reset BV 2 R/W DO 1 BO 1 Special* OFF X X X X X Network Input used to reset the C1 Runtime Alarm (BV:17) once the event is triggered
C1 Status BV 3 R DI 10002 BI 2 nvoC1Status NA X X X X X Indicates if Compressor 1 is "ON" or "OFF".
System Reset BV 4 R/W DO 2 BO 2 nviSystemReset OFF X X X X X
Network Input used to reset the unit from lockout mode. User must turn it "ON" then turn it "OFF",
not a momnetary switch.
C2 Reset BV 5 R/W DO 3 BO 3 Special* OFF X X X X X Network Input used to reset the C2 Runtime Alarm (BV:17) once the event is triggered
C2 Status BV 6 R DI 10003 BI 3 nvoC2Status NA X X X X X Indicates if Compressor 2 is "ON" or "OFF".
Dirty Filter Reset BV 7 R/W DO 4 BO 4 nviDFReset OFF X X X X X Network Input used to reset the Dirty Filter Alarm (BV:19).
Emergency Shutdown BV 8 R/W DO 5 BO 5 nviESD OFF X X X X X Network Input for Emergency ShutDown. When Engaged, Y1,Y2,G & W output relays turn "OFF".
Supply Fan Operational
Mode
BV 9 NA NA NA NA NA NA X X Sets Supply Fan Mode Auto-OFF, ON ON GEN2 , GEN3 and GEN 4 only
SF Status BV 10 R DI 10004 BI 4 nvoSFStatus NA X X X X X Indicates if the Supply Fan is "ON" or "OFF".
Occupied Status BV 11 R
DI
10005
BI 5
nvoOccStatus NA X X X X X Indicates whether the WSHP is in Occupied "ON" or Unoccupied "OFF" Mode.
Occupied Mode BV 12 R/W DO 7 BO 7 N/A ON X X X X X
Network Input to put WSHP in unoccupied Mode "OFF" or Occupied Mode "ON". Can be used
instead of Work Schedule.
Air Duct Mode BV 41 R/W DO 26 BO 30 nviDuctMode OFF X X X
Network Input used to activate Air Duct Mode. The Air Duct Mode uses Aux 5 Temp for the
controlling zone temperature.
AUX 5 BV 42 R DI 10026 BI 22 nvoAux5 NA X X X
Indicates the status of Aux Input 5 when RNet (BV:44) is "ON". And AUX5 CFG ( BV:46) is set to
"OFF" for Binary Input.
AUX 6 BV 43 R DI 10027 BI 23 nvoAux6 NA X X X
Indicates the status of Aux Input 6 when RNET (BV:44) is "ON". And AUX6 CFG ( BV:47) is set to
"OFF" for Binary Input.
RNet Mode BV 44 R/W DO 27 BO 31 nviRnetMode ON X X X
Network Input used to select between LSTAT (ASW06-08) wall sensors and communicating was
sensors(ASW13-15). RNet should be "OFF" when using LSTAT Sensors and "ON" for all other
congurations. The MPC board jumper W3 must be set to LSTAT for LSTAT sensors or RNet for
RNet sensors.
Humidity Occupancy BV 45 R/W DO 28 BO 32 nviRHOcc OFF X X X Network Input used to enable/ disable humidity control when AUX CFG (AV:31) set to 12 .
Aux 5 Cong BV 46 R/W DO 29 BO 33 nviAux5Cfg ON X X X
Network input used to select the conguration of Auxillary Input 5. Setting RNet (BV:44 ) "ON"
sets input for Thermistor mode,"OFF" sets input for Dry Contact mode.
Aux 6 Cong BV 47 R/W DO 30 BO 34 nviAux6Cfg ON X X X
Network input used to select the conguration of Auxillary Input 6 .Setting RNet (BV:44 ) "ON"
sets input for Thermistor mode,"OFF" sets input for Dry Contact mode.
DB Mode BV 48 R/W DO 31 BO 35 nviDBMode OFF X X X
Network input to select between using separate cooling and heating setpoints. Set to "OFF for
Cooling or Heating Setpoint or "ON" for the cooling setpoint and deadband to determne the heating
setpoint. Used when replacing GEN 4 or Lower with GEN 6 or higher.
CO2 Alarm BV 49 R DI 10028 BI 24 nvoCO2Alarm NA X X X
Indicates the CO2 status (AV:52) is above the CO2 trippoint (AV:54) when using an appropriate
wall sensor.
VOC Alarm BV 50 R DI 10029 BI 25 Special* NA X X X
Indicates the CO2 status (AV:53) is above the VOC trippoint (AV:55) when using an appropriate
wall sensor.
Fan Speed Enable BV 51 R/W DO 32 BO 36 Special* X X
Network input to activate the auxillary output for High Speed Fan when AUX CFG (AV:31) is set
to 5 for Fan Speed Control: Required Field wired Relay for PSC Motors only.
Compressor Shutdown BV 52 R/W DO 33 BO 37 Special* OFF X X
Network input used to shutdown all compressor functions, C1 and C2. Compressors Enabled =
"ON", Compressors disableld = "OFF"
Fault MSV 1 R NA NA NA NA NA X X X Multistate BACnet value for text description of current alarm state.
AUX Cong Status MSV 2 R NA NA NA NA NA X X X Multistate BACnet value for text description of current Auxillary Output Conguration..
Zone Mode Status MSV 3 R NA NA NA NA NA X X X Multistate BACnet value for text description of current operating mode.
Heating Mode BV 61 R/W DI 78 BI 74 Special* ON X
This is used to disable heating demand when it is desired to run Cooling Mode only. "ON"= Heating
Enabled, "OFF"= Heating Disabled. Special feature in GEN6, Standard Feature in GEN7.
