THE SMART SOLUTION FOR ENERGY EFFICIENCY
MPC MultiProtoCol DDC Controls
November 19, 2018
48
This section covers the installation and setup of the
Android Application from OEMCntl that allows an
Android capable tablet/Phone to replace the physical
Equipment Touch module. The tablet/ phone must have
an available USB connection. Most all phones will require
a micro or sub micro USB to standard USB adapter.
(See Figure 22.)
Required Components:
Tablet Model Used: RCA Galileo PRO
Operating System: Android 6.0 (Marshmallow).
USB Cable: AAPPLDRKIT KIT, SW, MPC, APPLDR/
VBAVIEW/ EQ TOUCH
App: Equipment Touch(OEM), Available at Google Play
store. WWW.play.GOOGLE.com
Vendor: OEMCntl, Cost: $29.00
Installation
1. The rst step is to go to play.GOOGLE.com
(Google Store) and download the Android
Equipment Touch application on to the Tablet or
Phone to be used in this application. Note: Each
individual device to be used must have a separate
license. At this point in time, the license cost is
$ 29.00 per device.
2. Once the Equipment Touch Application is
installed, Connect the USB dongle included in the
AAPPLDRKIT ( See Figure 1.)to the Tablet or Phone
(As stated before, the phone may require an Micro
USB to USB adapter. See Figure2.)
3. Connect a cable from the MPC USB port to
the Dongle.
4. Launch the Equipment Touch Application.
5. When the app starts it will bring up a device list in
which you will click on the USB Device. The App
will begin to load and will then bring up the Main
Equipment Touch menu.
6. At this point you can use the Tablet or Phone to
set up and monitor the MPC just as if it had an
Equipment Touch Screen attached.
7. One nal note: Equipment Touch has built in
Temperature and Humidity Sensors allowing it to
function as a Wall Sensor. Obviously, the Tablet/
Phone does not so it cannot function in this mode.
Android App Instalation
Figure 22: USB Dongle and Cable
Figure 23: Micro USB to USB Adapter
