ClimateMaster MPC User Manual

THE SMART SOLUTION FOR ENERGY EFFICIENCY
MPC MultiProtoCol DDC Controls
November 19, 2018
34
AUX CFG Mode (AV:31) Value Gen 3 Gen 4 Gen 6 Gen 7
Electric Heat when Demand > 90% 1 X X X X
Cycle with Y1 2 X X X X
Cycle w/ G 3 X X X X
Slow Opening Water Valve 4 X X X X
High Speed Fan 5 X X X X
Alarm Relay 6 X X X X
Reheat ICM/DXM Std 7 X X X
Reheat ICM/DXM Rev 8 X X X
Reheat DXM Std 9 X X X
Reheat DXM Rev 10 X X X
Manual Control 11 X X X X
Humidity Control 12 X X
CO2 Control 13 X X
VOC Control 14 X X
Full time Electric Heat 15 X
SF CFG ( AV:33 ) Value Gen 3 Gen 4 Gen 6 Gen 7
Cycle with Compressor 1 X X X X
On during occupancy, cycle with
Compressor during unoccupancy
2 X X X X
On all the Time 3 X X X X
Load Balance Select Mode (AV:59) Value Gen 3 Gen 4 Gen 6 Gen 7
Runtime Compare Mode 1 X
Manua Mode, C1 -Stage 1/ C2-Stage 2 2 X
Manua Mode, C2 -Stage 1/ C1-Stage 2 3 X
Time Toggle Mode- Toggles every 12 Hrs 4 X
SF CFG (AV:33) Value Gen 3 Gen 4 Gen 6 Gen 7
Supply Fan is ON anytime the
compressor is ON
1 X X X X
Supply F an ON only when in occupied
hours and the compressor is ON
2 X X X X
Supply Fan is ON all the time regardless
of occupancy or compressor state
3 X X X X
AUX CFG Settings
Supply FAN Settings
Compressor Load Balance Select Settings
Supply Fan Conguration Settings
Multi Generation Water-to-Air Points Matrix
