COBHAM SAILOR Global Xpress Modem Unit GMU User Manual

98-175666-A Appendix F: Event messages F-4
List of events
08085-0 ADM WARNING Radome temp too
high
The temperature in the radome is too high.
08086-0 ADM WARNING GPIO Tx mute active Tx has been muted from GPIO on the BDU. (!T)
08087-0 ADM WARNING Temperature
protection
Temperature too high. BUC shut down.
08088-0 ADM WARNING Antenna data not
synchronised
Persistent antenna data not synchronized in all
backup locations. Retry will happen on next boot.
Info code shows sum of all outdated copies Info:
0x00000002 ISCM 0x00000004 Azimuth IFDM
0x00000008 Cross elevation IFDM
0x00000010 Elevation IFDM 0x00000020
Polarisation IFDM (!T)
0810A-0 ADM ERROR ASCM production
data
Production data has been corrupted.
0810F-0 ADM ERROR ASCM Devices Startup of ascm_devs application failed.
08110-0 ADM ERROR ASCM - APSM
Communication
Communication between ASPM and ASCM.
08111-0 ADM ERROR Presence of EBUS
devices
Present EBUS devices matches antenna type. The
info code shows the sum of all missing or
unexpected modules, see below: 0x00000001:
Azimuth IFDM 0x00000002: Cross Elevation IFDM
0x00000004: Elevation IFDM 0x00000008: ISCM
0x00000010: Polarisation IFDM
08112-0 ADM ERROR Elect of antenna data No antenna data blob was elected.
08113-0 ADM ERROR APSM production
data
APSM production data is corrupted.
08114-0 ADM ERROR ASCM FS File system partition corrupt
0850A-0 ADM ERROR GNSS Initialization GNSS initialization failed.
0851E-0 ADM ERROR Sensor sanity Too many invalid values measured by the ISM
during initialisation. Check for vibrations or
malfunctioning ISM.
08521-0 ADM ERROR Azi axis calibration Azimuth axis zero reference not found. Check belt
and zero reference module. Info: 0x00000001:
Timeout (operation did not complete in time)
0x00000010: Encoder or mechanical problem
0x00000020: Zero reference not found
0x00000040: End stop not found.
08522-0 ADM ERROR Xel axis calibration Cross-elevation axis zero reference or end stops
not found at expected locations. Check belt, zero
reference module, and end stops. Info: See 08521-
0.
ID Module Type Description Explanation
Table F-1: Event messages (Continued)
