InteliLite4 AMF20 Global Guide
300
Subgroup: Timer 2
Timer 2 Function
Setpoint group Scheduler Related FW 1.3.0
Range [units]
Disable / Manual On / No Func / TEST / Test OnLd / MFail Blk / Rem Start/Stop / Auto
Run / Mode OFF [-]
Default value No Func Alternative config NO
Step [-]
Comm object 15359 Related applications AMF,MRS
Config level Standard
Setpoint visibility Always
Description
Note: It is possible to choose from following Timer functions. Binary output EXERCISE TIMER 2 (PAGE
476) is always activated when Timer is active regardless of chosen timer function. Timer functions
require controller running in AUTO mode.
Timer 1 has higher priority over Timer 2. So if Timer 1 Function (page 292) is configured for OFF mode
and Timer 2 Function (page 300) is over the same time configured for AUTO mode, controller will work in
OFF mode.
Controller activates timer whenever it is powered up even in period, where timer should be already
running.
Disable The Timer is disabled.
Manual On LBO Timer is active, but the Timer itself is disabled.
Note: This function serves for testing purposes.
No Func There is no any other function, only binary output of timer is activated.
Mode OFF When this option is chosen then the binary output of timer is internally connected to
the REMOTE OFF (PAGE 458) binary input.
Rem
Start/Stop
When this option is chosen then the binary output of timer is internally connected to
the REMOTE START/STOP (PAGE 459) binary input.
TEST When this option is chosen then the binary output of timer is internally connected to
the binary input REMOTE TEST (PAGE 460).
TEST OnLd When this option is chosen then the binary output of timer is internally connected to
the REM TEST ON LOAD (PAGE 456) binary input.
MFail Blk When this option is chosen then the binary output of timer is internally connected to
the MAINS FAIL BLOCK (PAGE 451) binary input.
6 back to List of setpoints
