Switching of gen-sets
Switching of gen-sets is based on their Running Hours (page 497). The time how long the gen-set is running is
adjusted via setpoint Running Hours Max Difference (page 263). When difference of Running Hours (page
497) between gen-sets is bigger then value adjusted in this setpoint, load is transferred from first gen-set to
second gen-set. First gen-set is supplying the load until second gen-set is in running state. Then the GCB of first
gen-set is opened. From this moment timer Transfer Delay (page 256) counts down. When it counts down,
GCB of second gen-set can be closed.
Note: Value of Running Hours (page 497) can be modified by setpoint Running Hours Base (page 264).
This setpoint can add or remove additional running hours to value from statistics. This modified value of running
hours is used in dual operation function.
Note: In case that both gen-sets have the same running hours, Master controller has higher priority.
Note: Switching of gen-sets can be inhibit by setpoint Swap Gen-sets (page 264) or by binary input DUAL
SWAP GEN-SETS (PAGE 552).
Note: Priority of gen-set can be changed by binary input DUAL TOP PRIORITY (PAGE 552). In this case running
hours values are not used to decide, which gen-set should start.
Dual operation adjustment
Prepare two InteliLite AMF25 or two InteliLite MRS16 controllers with CM-RS232-485 modules
Copy the identical configurations to both of them
Use wiring with mechanical/electrical interlock between all breakers (mechanical interlock is preferred)
Switch both controllers to OFF mode to prevent automatic or remote start
Adjust setpoints COM1 Mode (page 367) or COM2 Mode (page 369) (depends on prefered communication
line) to DualMaster on first controller and Dual Slave on second controller
Interconnect communication terminals on CM-RS232-485 modules
Adjust setpoint MCB Opens On (page 263) to Mains Fail option
Adjust setpoint Running Hours Max Difference (page 263) on Master controller
Adjust setpoints Running Hours Base (page 264) on both controllers if running hours change is needed for
dual operation
Adjust additional function of dual operation - Master Error Protection (page 265), Slave Error Protection
(page 265) and Swap Gen-sets (page 264) setpoints
Change the mode of both controllers to AUTO
System is now ready for dual operation function
Note: Breakers feedbacks are recommended, but not required.
Alarms related to dual operation:
Dual Operation Fail (page 703)
Dual Operation Master Fail (page 703)
Dual Operation Slave Fail (page 703)
Dual Operation Different Mains (page 702)
Dual Operation Different FW Version (page 702)
