InteliLite
NT
– AMF20/25, SW version 1.2, ©ComAp – March 2008 35
IL-NT-AMF-Reference Guide1.2.pdf
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
AL Gen Freq
Output closes if the generator over/under frequency alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
AL Gen >Freq
Output closes if the generator over frequency alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
AL Gen <Freq
Output closes if the generator under frequency alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
AL Mains Volts
The output closes if the mains over/under voltage alarm or voltage asymmetry alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
AL Mains Freq
Output closes if the mains over/under frequency alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
AL Overload Sd
Output closes if the generator overload alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
AL Stop Fail
Output closes when the engine have to be stopped, but speed or frequency or voltage or oil pressure
is detected. This protection goes active 60s after stop command. With start goes this protection
inactive.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
AL Overspeed
Output closes if the gen-set overspeed alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
