Compaq Armada 1700 User Manual

Connectors A-5
Table A-8
Continued
Pin Signal Pin Signal
61 GND 96 GND
62 AD[14] 97 CBE3
63 AD[15] 98 AD[21]
64 AD[1] 99 NC
65 AD[3] 100 NC
66 AD[2] 101 AD[18]
67 GND 102 C/BE1
68 MDATA 103 PAR
69 KBDATA 104 GND
70 MCLK 105 AD[16]
71 KBCLK 106 AD[6]
72 ACVCC 107 C/BE0
73 PMVCC5 108 AD[5]
74 PMVCC5 109 AD[7]
75 NC 110 AD[4]
76 BLUE 111 BATTLED
77 NC 112 SWC
78 PBUSY 113 TA
79 PDATA7 114 SWB
80 PBDATA3 115 SWD
81 PSLIN 116 SWA
82 GND 117 PMVCC5
83 GND 118 PMVCC5
84 SPK_IN 119 PMVCC5
85 +5v 120 PMVCC5
86 NC 121 PSELECT
87 ERDY 122 PDADA6
88 SYSVCC5A 123 PACK
89 STANDBy_SW 124 PDATA2
90 NC 125 PDATA0
91 NC 126 PFAULT
92 NC 127 GND
93 NC 128 GND
94 GNT1 129 DSRA
95 GND 130 DCDA
Continued
