Compaq Armada 1700 - Page 137

A-6 Connectors
Table A-8
Continued
Pin Signal Pin Signal
131 RTSA 154 AD[8]
132 RIA 155 PORT_REP
133 POWER_SW 156 MSI
134 INTB 157 MSO
135 NC 158 TC
136 INTA 159 TD
137 NC 160 TB
138 GND 161 PMVCC5
139 NC 162 PMVCC5
140 AD[27] 163 PPE
141 AD[30] 164 PMVCC5
142 AD[26] 165 PDATA4
143 AD[29] 166 PDATA5
144 AD[25] 167 PDATA1
145 AD[28] 168 PINIT
146 AD[24] 169 PSTB
147 BLOCK 170 PAFD
148 GND 171 GND
149 PERR 172 GND
150 SERR 173 CTSA
151 AD[11] 174 SINA
152 AD[9] 175 DTRA
153 AD[10] 176 SOUTA
