Compaq dc5800 - Microtower PC Reference Guide

24-Pin MicroFit Power (CMT, SFF)
Connector
24
12
13
1
Front
Pin Signal Pin Signal Pin Signal Pin Signal
1
2
3
4
5
6
+5 Vaux
GND
+5V
+5V
PS_ON
GND
7
8
9
10
11
12
PWRGD
+3.3V
+3.3V
Tach
GND
Fan-CMD
13
14
15
16
17
18
+12V
+5V Sense
GND
+5V
+5V
+3.3V
19
20
21
22
23
24
GND
+3.3V
Sense
+3.3V
+3.3V
GND
4-Pin Power (for CPU)
Connector and Icon Pin Signal
1
2
3
4
GND
GND
+12V CPU
-12V CPU
6-Pin Power (for CPU) (CMT, SFF)
Connector and Icon Pin Signal
6
4
1
2
3
4
5
6
GND
GND
GND
12V CPU
12V CPU
+12V
24-Pin MicroFit Power (CMT, SFF) 173

Compaq dc5800 - Microtower PC Specifications

General

Processor	Intel Core 2 Duo, Intel Pentium Dual-Core, Intel Celeron
Memory	Up to 8 GB DDR2 SDRAM
Graphics	Integrated Intel Graphics Media Accelerator 3100
Optical Drive	DVD-ROM, DVD+/-RW
Form Factor	Microtower
Expansion Slots	1 PCI, 2 PCIe x1, 1 PCIe x16
Audio	Integrated High Definition Audio
Network	Integrated Gigabit Ethernet
Ports	VGA, Serial, Parallel, PS/2, Audio in/out
Operating System	Windows Vista Business, Windows XP Professional
Power Supply	300W
USB Ports	8 USB 2.0 (2 front, 6 rear)
