Cable Connections
System board connectors are color-coded to make it easier to find the proper connection.
System Board Connections
System Board Connector, Name, and Connector Color Description
P1, PWR, black Power supply, 24-pin
P3, PWRCPU, black Power supply, 4-pin
P10, FLOPPY, black Diskette drive
P8, CPU FAN, white Heatsink fan
P9, CHASSIS FAN, brown or red Chassis fan
P5, PB/LED, black Front power button/LED
P24, FRNT USB, Yellow Front I/O USB cable
P23, FRNT I/O, black Front I/O audio
P6, SPKR Internal speaker
P150, MEDIA CARD Media card reader
P11, REAR FAN, red/maroon Rear fan
P12, FRONT_AUD, white Front audio
Power Supply Cable Connections
Power Supply Connector ID Description
P1 Main power
P3 CPU power
P4 1st Hard drive, SATA0
P5 2nd HDD
P6 PATA/Zip/Media card reader
P8 Diskette drive
P9 1st ODD or 2nd HDD if no ODD present, SATA1
P10 2nd ODD
P11 3rd ODD
Cable Management 69
