Compaq dc5800 - Microtower PC Reference Guide

52
53
54
55
GND
GND
PETp9
PETn9
57
58
59
60
GND
PETp10
PETn10
GND
62
63
64
65
PETp11
PETn11
GND
GND
67
68
69
70
PETn12
GND
GND
PETp13
72
73
74
75
GND
GND
PETp14
PETn14
76
77
78
79
80
GND
GND
PETp15
PETn15
GND
81
82
PRSNT2#
RSVD
NOTE: x1 PCI Express uses pins 1-18
x4 PCI Express uses pins 1-32
x8 PCI Express uses pins 1-49
x16 PCI Express uses pins 1-8
PCI Express Mini Card
PCI Express Mini Card Connector
Pin Signal Pin Signal Pin Signal Pin Signal Pin Signal
1
2
3
4
5
6
WAKE#
3.3V
Reserved**
GND
Reserved**
1.5V
7
8
9
10
11
12
CLKREQ#
UIM_PWR
GND
UIM_DATA
REFCLK-
UIM_CLK
13
14
15
16
17
18
REFCLK+
UIM_RESET
GND
UIM_VPP
Reserved ***
(UIM_C8)
GND
19
20
21
22
23
24
Reserved***
(UIM_C4)
W_DISABLE#
GND
PERST#
PERn0
+3.3Vaux
25
26
27
28
29
30
PERp0
GND
GND
+1.5V
GND
SMB_CLK
176 Appendix A Connector Pin Assignments

Compaq dc5800 - Microtower PC Specifications

General

Processor	Intel Core 2 Duo, Intel Pentium Dual-Core, Intel Celeron
Memory	Up to 8 GB DDR2 SDRAM
Graphics	Integrated Intel Graphics Media Accelerator 3100
Optical Drive	DVD-ROM, DVD+/-RW
Form Factor	Microtower
Expansion Slots	1 PCI, 2 PCIe x1, 1 PCIe x16
Audio	Integrated High Definition Audio
Network	Integrated Gigabit Ethernet
Ports	VGA, Serial, Parallel, PS/2, Audio in/out
Operating System	Windows Vista Business, Windows XP Professional
Power Supply	300W
USB Ports	8 USB 2.0 (2 front, 6 rear)
