C-Band Transceiver Revision 1

CSAT-5060 5 to 25 Watt Installation MN/CSAT5060.IOM

A–15

Item Part No. Nomenclature QTY

1 CA/RF0097 Cable, Output RF 4

2 CA/WR0051 Cable, Control-LNA Switch 1

3 CA/WR0052

Cable, Control-

TX Switch

4 CA/WR0053 Cable, Communication 1

5 CA/WR0053 Cable, Communication 1

Figure A-16. Cable Kit, AS/0440
