Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
Ethernet Interface Operation 4–21 MN-LPOD
Amplifier
Name
Description
Attenuation (dB)
Enter a valid attenuation level (00.00 to 20.00 dB) in 0.25 dB steps.
Attenuation Offset
Enter a valid offset value, in dB.
Fault Recovery
Use the drop-down list to select Automatic or Manual.
Mute
Use the drop-down list to select Enabled or Disabled.
Aux Mute
Use the drop-down list to select Enabled or Disabled.
Offline Mute
Use the drop-down list to select Enabled, Disabled, MuteRx, MuteTx,
MuteRx+LNB, MuteTx+LNB, Mute Tx+Amp, or Mute Tx+LNB+Amp.
Click [Reset] to restore the previously saved settings.
Click [Change Configuration] to save any changes.
Reference
Name
Description
Ref Freq Adjust
Enter a valid reference oscillator tuning voltage value from 0 to 255. The
default value is set to 87.
Ext Ref Mute
Use the drop-down list to select the External Reference Not Present Mute
Mode as either Enabled or Disabled.
Click [Reset] to restore the previously saved settings.
Click [Change Configuration] to save any changes.
Low Power Forward Threshold (dBm)
When the forward power monitor is set to Alarm or Fault instead of the factory default of Mask,
and the forward power drops below the specified value, the alarm/fault occurs.
Set the threshold value, in dBm, for the low forward power alarm/fault.
To disable the threshold, set this parameter to the default value of 00.00.
Click [Change] to save any changes.
FSK Address
Set the FSK (Frequency Shift Keying) Address from 01 to 15.
Click [Change] to save any changes.
