Comtech EF Data LPOD PS 1.5 - Physical

Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
Introduction 1–11 MN-LPOD
1.5.5 Physical
Weight
PS 1, 1.5
17 lbs. (9.1 kg) Nominal
PS 2
47 lbs (21.32 kg) Nominal
Dimensions
(excluding
connectors)
See Sect. 1.6 for all
dimensional envelope
figures
PS 1
12.65 x 6.26 x 7.37 in.
(321.3 x 159 x 187.2 mm)
PS 1.5
12.78 x 6.14 x 7.05 in.
(324.6 x 156 x 179.1 mm)
PS 2
16.18 x 8.80 x 9.78 x in.
(427 x 223.5 x 248.4 mm)
Connectors
IF/RF Input
Type ‘N’ Female
RF Output
PS 1
C-Band / X-band: Type ‘N’ Female (standard),
CPR137G (optional)
Ku-Band: WR75 (No groove)
PS 1.5
C-Band: CPR137G
X-Band: CPR112G
Ku-Band: WR75 (No groove)
PS 2
C-Band: CPR137G
X-Band: CPR112G
Ku-Band: WR75 (No groove)
LNB Bias
Type ‘N’ Female
M&C/Ethernet/
Redundancy Switches
19-pin MS style (single integrated cable assembly
available, dependent upon configuration)
