Comtech EF Data LPOD PS 1.5 - Single Unit Mounting Kit (KT-0000125) for PS 2

Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
System Connectors, Installation, and Startup 2–19 MN-LPOD
2.4.3.3 Single Unit Mounting Kit (KT-0000125) for PS 2
Use this kit in combination with the Universal Pole Mounting Kit (PL/12319-1).
Item
Qty
CEFD Part No.
Description
1
2
FP-0000442
BRACKET, MOUNTING
2
2
FP/BR0078
UNISTRUT, DUAL CHANNEL
3 4 HW-0000070
SCREW, HEX, SERRATED FLANGE HEAD,
3/8-16 x 3/4 LG, SS
4 4 HW/3/8SPRINGNUT
SPRINGNUT, SHORT SPRING, 3/8-16, SS
(P3300)
5
4
HW/5/16-18X3/4B
BOLT, HEX HEAD, 5/16-18 X 3/4 LG, SS
6
4
HW/5/16-SPLIT
LOCK WASHER, SPLIT, 5/16
7
4
HW/5/16-FLT
WASHER, FLAT, 5/16
Figure 2-11. Single Unit Mounting Kit (KT-0000125) for PS 2
