Comtech EF Data LPOD PS 1.5 - KT-0000116 LPOD Rx Splitter; Cable Kit

Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
Appendix A A–14 MN-LPOD
A.4.1.2 KT-0000116 LPOD Rx Splitter / Cable Kit
Item
Qty
CEFD Part No.
Description
10
2
FP-0000580
SPACER PLATE, RF SPLITTER / COMBINER
20
2
HW/4-FLT
#4 FLAT WASHER, SS
30
1
RF-0000105
RF POWER SPLITTER/COMBINER, 2-WAY, 0 DEGREES, 1-2GHZ
40
2
HW/4-40X1.25PH
#4-40 x 1.25 LG PAN HD PHILLIPS SCREW, SS
50
2
CA/RF0097
CABLE ASSY, CONNECTOR, CSAT-7075 OUTPUT RF, ROHS
60
2
HW/4-SPLIT
#4 SPLIT LOCK WASHER, SS
70
6
HW/TW14.5HDBLK
CABLE TIE, 14.5", HEAVY DUTY, BLACK
Figure A-5. KT-0000116 LPOD Rx Splitter / Cable Kit Example – Exploded and Assembled Isometric Views
