Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
Appendix A A–22 MN-LPOD
Item
Qty
CEFD Part No.
Description
1
1
SW/WGS28V-75SB
SWITCH, WAVEGUIDE, WR75, +28VDC, SEALED, SIDE & BOTTOM MNT
2
1
RF/TRF-KU-WR75G
RF TRANSMIT REJECT, WR75, GROOVED
3
7
GA/GSKTWR75HALF
GASKET, WR75, HALF THK
4
1
FP/6072
PLATE, SHORTING, WR75G
5
2
FP-0001006
WAVEGUIDE, WR-75, 90-DEG ELB, #6/M4 FLANGE CLEARANCES
6
16
HW/6-32X1/2SHCS
#6-32 x 1/2 LG SOCKET HD CAP SCREW, SS
7
4
HW/6-32X7/8SHCS
#6-32 x 7/8 LG SOCKET HD CAP SCREW, SS
8
20
HW/6-SPLIT
#6 SPLIT LOCK WASHER, SS
9
24
HW/6-FLT
#6 FLAT WASHER, SS
10
4
HW/6-32HEXNUT
#6-32 HEX NUT, SS
11
3
HW-0000313
GASKET, WR75, FLAT, CONDUCTIVE
12
8
HW/M4LOCK
M4 SPLIT LOCK WASHER, SS
13
16
HW/M4FLAT
M4 FLAT WASHER, SS
14
8
HW/M4X.07HEX
M4 x .07 HEX HUT, SS
15
8
HW/M4X12SHCS
M4 x 12 LG SOCKET HEAD CAP SCREW, SS
16
8
HW/M4X25SHCS
M4 x 25 LG SOCKET HEAD CAP SCREW, SS
Figure A-10. KT-0000191 Ku-Band Rx Switch Kit Example, OMT-Mounted, Metric – Exploded Isometric View
