Item
Qty
CEFD Part No.
Description
1
4
FP-0000534
BRACKET, MOUNTING, LPOD PS 1
2
2
FP-0000542
CHANNEL, DUAL, UNISTRUT, 1:1 RDNT, LPOD PS 1
3
1
FP-0000537
BRACKET, UNIVERSAL, 1:1 RDNT, LPOD PS 1
5
2
FP-0000580
SPACER PLATE, RF SPLITTER / COMBINER
10
4
CA/6357-2
CABLE, ROHS, TX, 2FT
11
1
HW/CAP-SS14
DUST COVER,RECEPTACLE,NON-SHORTING,SIZE 14,SS,W/CHAIN & RING
20
1
SW/COAX-N-F-SEALED
SWITCH COAX N-FEMALE, 25VDC 5.9-6.5 SEALED
21
1
RF-0000104
TERMINATION, MOD, TYPE N, M, 50 W, DC-8.5 GHz
22
1
RF-0000105
SPLITTER/COMBINER, RF POWER, 2-WAY, 0 DEGREES, 1-2GHZ
30
8
HW/1/4-20X1/2FH
1/4-20 x 1/2 LG FH PHILLIPS SCREW, 82, UCUT, SS
31
10
HW-0000070
3/8-16 x 3/4 LG HEX, FLNG, SERR SCREW, SS
32
10
HW/3/8SPRINGNUT
SPRINGNUT, 3/8-16, SHORT SPRING, SS (P3300)
33
2
HW/4-FLT
#4 FLAT WASHER, SS
34
2
HW/4-SPLIT
#4 SPLIT LOCK WASHER, SS
35
2
HW/4-40X1.38PH
#4-40 x 1/38 P.H. PHIILIPS SCREW, SS
37
4
HW/6-FLT
#6 FLAT WASHER, SS
38
4
HW/6-SPLIT
#6 SPLIT LOCK WASHER, SS
39
4
HW/6-32X5/16P.H
#6-32 x 5/16 LG PHILLIPS SCREW
40
2
HW-0000170
M4X0.7 x 8 LG PAN HD PHILLIPS SCREW, SS
41
2
HW/M4LOCK
M4 LOCK WASHER, SS
42
2
HW/M4FLAT
M4 FLAT WASHER, SS
43
12
HW/TW14.5HDBLK
CABLE TIE, 14.5", HEAVY DUTY, BLACK
Figure A-14. KT-0000090 LPOD PS 1 C-Band Coax Output 1:1 Redundancy Kit Example – Exploded Isometric View
