Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
Appendix A A–31 MN-LPOD
Item
Qty
CEFD Part No.
Description
1
4
FP-0000534
BRACKET, MOUNTING, LPOD PS 1
2
2
FP-0000542
CHANNEL, DUAL, UNISTRUT, 1:1 RDNT, LPOD PS 1
3
1
FP-0000537
BRACKET, UNIVERSAL, 1:1 RDNT, LPOD PS 1
4
1
FP-0000548
WAVEGUIDE, Ku, WR-75, GRVD FLGS, E TO H TO FLEX, LH, 1:1, PS 1
5
1
FP-0000549
WAVEGUIDE, Ku, WR-75, GRVD FLGS, E TO H TO FLEX, RH, 1:1, PS 1
7
2
FP-0000580
SPACER PLATE, RF SPLITTER / COMBINER
8
1
FP-0000645
BRACKET, SUPPORT, 1:1 RED., LPOD PS 1
11
2
CA/RF0097
CABLE ASSY, ROHS CONNECTOR, CSAT-7075 OUTPUT RF, ROHS
12
1
HW/CAP-SS14
DUST COVER,RECEPTACLE,NON-SHORTING,SIZE 14,SS,W/CHAIN & RING
20
1
SW/WGS28V-75SB
SWITCH, WAVEGUIDE, WR75, +28VDC, SEALED, SIDE & BOTTOM MNT
21
1
RF/TERM-11923-5
RF TERMINATION, WR75G, 14-14.5GHz, 1.05:1 VSWR, 150W
22
1
RF-0000105
RF POWER SPLITTER/COMBINER, 2-WAY, 0 DEGREES, 1-2GHZ
23
6
GA/WR75-R-H-C
GASKET, O RING, WR-75, HALF THICKNESS, CONDUCTIVE
24
12
HW/TW14.5HDBLK
CABLE TIE, 14.5", HEAVY DUTY, BLACK
30
8
HW/1/4-20X1/2FH
1/4-20 x 1/2 FLAT HD PHILLIPS SCREW, 82°, UCUT, SS
33
10
HW-0000070
3/8-16 x 3/4 LG SCREW, HEX, FLNG, SERR, SS
34
10
HW/3/8SPRINGNUT
SPRINGNUT, 3/8-16, SHORT SPRING, SS (P3300)
35
2
HW/4-FLT
#4 FLAT WASHER, SS
36
2
HW/4-SPLIT
#4 SPLIT LOCK WASHER, SS
37
2
HW/4-40X1.38PH
#4-40 x 1-3/8 LG PAN HD PHILLIPS SCREW, SS
39
28
HW/6-FLT
#6 FLAT WASHER, SS
40
28
HW/6-SPLIT
#6 SPLIT LOCK WASHER, SS
41
4
HW/6-32X5/16P.H
#6-32 x 5/16 LG PHILLIPS SCREW
42
20
HW/6-32X1/2SHCS
#6-32 x 1/2 LG SOCKET HD CAP SCREW, SS
43
4
03P1111
#6-32 x 9/16 LG SOCKET HD SCREW, SS
44
2
HW/8-32X1/2SHCS
#8-32 x 1/2 LG SOCKET HD CAP SCREW, SS
45
4
HW/8-FLT
#8 FLAT WASHER, SS
46
2
HW/8-SPLIT
#8 SPLIT LOCK WASHER, SS
47
2
HW/8-32HEXNUT
#8-32 HEX NUT, SS
Figure A-16. KT-0000089 LPOD PS 1 Ku-Band 1:1 Redundancy Kit Example – Exploded Isometric View
