Comtech EF Data LPOD PS 1.5 - Page 200

Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
Appendix A A–38 MN-LPOD
Item
Qty
CEFD Part No.
Description
30
2
FP-0000542
CHANNEL, DUAL, UNISTRUT
40
10
HW-0000070
SCREW, HEX, FLNG, 0.375-16 x 0.750, SS, SERR
50
10
HW/3/8SPRINGNUT
SPRINGNUT, 3/8-16, SHORT SPRING, SS (P3300)
60
4
FP-0020593
BRACKET, MOUNTING, DC LPOD
70
4
CA-0000348
CABLE ASSY, RF, 2 FT
80
1
HW/CAP-SS14
DUST COVER,RECEPTACLE,NON-SHORTING,SIZE 14,SS,W/CHAIN & RING
90
1
SW/WGS28V-137S
SWITCH, WAVEGUIDE, CPR137
100
1
FP/WG0034
MPS, BLANKET FP TERM
110
1
RF-0000105
RF POWER SPLITTER/COMBINER, 2-WAY, 0 DEGREES, 1-2GHZ
130
2
FP-0000580
SPACER PLATE, RF SPLITTER / COMBINER
140
1
FP-0020594
SUPPORT BRACKET
150
1
FP-0020595
OUTPUT WAVEGUIDE, UNIT 1 TO PORT 4
160
1
FP-0020596
OUTPUT WAVEGUIDE UNIT 2 TO PORT 2
170
1
FP-0020592
BRACKET, MOUNTING, LPOD PS 1.5
180
5
GA/GSKTCP137HLF
GASKET, CP137, HALF THK
190
40
HW/10-FLT
#10 FLAT WASHER, SS
200
40
HW/10-SPLIT
#10 SPLIT WASHER, SS
210
40
HW/#10-32X5/8SHC
#10-32 x 5/8 LG SOCKET HD CAP SCREW, SS
220
4
HW/SEM632X5/16PH
#6-32 x 5/16 LG PHILLIPS HD SCREW, SS
230
1
PP-0020512
BALL DRIVER
240
8
HW/1/4-SPLIT
1/4" SPLIT WASHER., SS
250
8
HW/1/4-20X3/4BT
1/4-20 x 3/4 LG BOLT
260
12
HW/TW14.5HDBLK
CABLE TIE, 14.5", HEAVY DUTY, BLACK
270
2
HW/SEM440X3/8PH
#4-40 x 3/8 LG PAN HD SCREW
280
5
HW/632X5/16FHMS
#6-32 x 5/16 FLAT HD MACHINE SCREW
Figure A-20. KT-0020526 LPOD PS 1.5 C-Band DC Option 1:1 Redundancy Kit Example – Exploded Isometric Views
