LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC) Revision 3
Appendix B MN-LPOD
B–9
Note: Where Parameter Type is in the format <description>
E
, while the underlying command will remain, the specific functionality will be
obsolete and should not be used for new implementations. There generally will be a different command elsewhere that encapsulates the marked
functionality.
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are printable ASCII
characters)
Response to
Command
(Target to Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Auto Fault
Recovery
AFR= 1 byte
Command or Query.
The LPOD output will automatically be muted if one of
the following fault conditions occurs: BUC lock detect
fault, LNB current fault (see Note), LNB voltage fault
(see Note). If auto fault recovery is enabled, it will
cause the output return to its pre-fault mute condition if
all faults are cleared. If disabled, the output will remain
muted even if all faults are cleared.
Example: <1/AFR=1’cr’
>0001/AFR=’cr’’lf’
Note: these faults can be user defined as faults,
alarms, or masked (see MSK command for more info).
Default Value: 1
AFR=
AFR?
AFR*
AFR? AFR=x
(Same format as
command
arguments.)
RF Power
Amplifier State
AMP= 1 byte Command or Query.
Turns ON or OFF the RF power amplifiers.
0 = Off
1 = On
Example: <1/AMP=1’cr’
>0001/AMP=’cr’’lf’
Note: turning the amplifier off will disable the +10V
supply, and mask it during fault checking.
Default Value: 0
AMP=
AMP?
AMP*
AMP? AMP=x
(Same format as
command
arguments)
Attenuation Offset
AOF= 5 bytes
Command or Query.
Valid attenuation level (00.00 to 20.00), in dB, in 0.25 dB
steps as factory default. This value is not copied to the
offline unit in a redundant system, but will be added to
the attenuation value upon a switchover. This provides a
unit specific fine-tune to maintain power levels
appropriately in a redundant system.
Example: <1/AOF=12.25’cr’
>0001/AOF=’cr’’lf’
Default Value: 00.00
AOF=
AOF?
AOF*
AOF? AOF=xx.xx
(Same format as
command
arguments.)
