LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC) Revision 3
Appendix B MN-LPOD
B–10
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are printable ASCII
characters)
Response to
Command
(Target to Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Attenuation ATT= 5 bytes Command or Query.
Valid attenuation level (00.00 to 20.00), in dB, in 0.25
dB steps as factory default.
Example: <1/ATT=12.25’cr’
>0001/ATT=’cr’’lf’
Default Value: 10.00
ATT=
ATT?
ATT*
ATT? ATT=xx.xx
(Same format as
command
arguments.)
Auxiliary Mute
Enable
AUX= 1 byte Command or Query.
Enables or disables the auxiliary mute mode.
0=Disabled
1=Enabled
Example (AUX Mute Enabled): AUX=1’cr’
Note: When enabled, the mute control input on the
remote com connector must be grounded to UN-MUTE
the unit. Otherwise, the unit will be muted, and if a mute
query is given (MUT?) the response will be MUT=2 to
indicate a hardware controlled mute is present.
Aux mute is one of several hardware mute states that
can cause a MUT=2 to be reported. See the MUT
command for more info on mute states.
Auxiliary mute supersedes the user mute state so if the
command MUT=1 is sent, then AUX=1 is sent, and the
user shorts Pin K to Pin S on the discrete control
connector then the RF mute will be disabled (MUT=0).
Default Value: 0
AUX=
AUX?
AUX*
AUX? AUX=x
(Same format as
command
arguments.)
Clear All Stored
Alarms
E
CAA= None Command only.
Instructs the LPOD to clear all Stored Alarms. This
command takes no arguments.
Example: <1/CAA=’cr’
>0001/CAA=’cr’’lf’
CAA=
CAA*
N/A N/A
Clear All Stored
Events
CAE= None Command only.
Instructs the SSPA to clear all Stored Events. This
command takes no arguments.
Example: <1/CAE=’cr’
>0001/CAE=’cr’’lf’
CAE=
CAE*
N/A N/A
