FSG/MTM/001 060511
99
4.2.5 Check and Adjustment of Scan-Width
Images of the Scan-Width adjustments are shown in:
Fig. 4-20 COUGAR 25, CHAMELEON 25, Scan-Width, page 102
Fig. 4-21 COUGAR 36, CHAMELEON 36, PREMIER 36, Scan-Width (A), page
103
Fig. 4-22 COUGAR 36, CHAMELEON 36, PREMIER 36, Scan-Width (B), page
103
Fig. 4-23 CHROMA Tx 40, CRYSTAL Tx 40, Scan-Width (A), page 104
Fig. 4-24 CHROMA Tx 40, CRYSTAL Tx 40, Scan-Width (B), page 104
Fig. 4-25 CHROMA Tx 40, CRYSTAL Tx 40, Scan-Width (C), page 105
Fig. 4-26 MAGNUM XL 54, Scan-Width (A), page 106
Fig. 4-27 MAGNUM XL 54, Scan-Width (B), page 106
Fig. 4-28 MAGNUM XL 54, Scan-Width (C), page 107
Fig. 4-29 MAGNUM XL 54, Scan-Width (D), page 107
Fig. 4-30 COUGAR Tx 36, CHAMELEON Tx 36, PREMIER Tx 36, Scan-Width
(A), page 108
Fig. 4-31 COUGAR Tx 36, CHAMELEON Tx 36, PREMIER Tx 36, Scan-Width
(B), page 108
The aim of this adjustment is to obtain a camera Scan-Width of:
COUGAR 25, CHAMELEON 25: 635 mm
COUGAR 36, CHAMELEON 36, PREMIER 36: 516 mm
CHROMA Tx 40, CRYSTAL Tx 40: 344.4/350.2/344.4 mm
MAGNUM XL 54: 350.9/358.9/358.9/350.9 mm
COUGAR Tx 36, CHAMELEON Tx 36, PREMIER Tx 36: 466.7 mm
The Scan-Width is correct if the total sum of Scan-Width Units (SWU) at the start and at the
end of the scanline is as shown in the table below (1 SWU is either 1 Black Line or 1 White
Space of the Scan-Width Pattern (A)).
Model Optical Adjustment Pattern Total sum of
Scan-Width
Units
Tolerance
COUGAR 25, CHAMELEON 25 6779D105, sub-pattern A 6 ±0.5 SWU
COUGAR 36, CHAMELEON 36,
PREMIER 36
6779D107, sub-pattern A 6 ±0.5 SWU
CHROMA Tx 40, CRYSTAL Tx 40 6779D102, sub-pattern A 6 ±0.5 SWU
MAGNUM XL 54 6779D130, , sub-pattern A 6 ±0.5 SWU
COUGAR Tx 36, CHAMELEON Tx
36, PREMIER Tx 36
6779D127, sub-pattern A 6 ±0.5 SWU
The tolerance corresponds to approximately 0.10% on the Scan-Width (scaling error).
Adjustment Procedure
Always do the Focus adjustment before adjusting the Scan-Width, see “Interaction” below.
