Contex COUGAR 36 - Fig. 4-45 Optical Adjustment Pattern, 25; Fig. 6-1 SM Calibration Sheet, 25; Fig. 6-2 SM Calibration Sheet, 40; Fig. 6-3 SM Calibration Sheet, 54

SOG/PLS/013 060328
9
Description Part Number
CRYSTAL HS 42 CHROMA HS 42 CRYSTAL XL42 CHROMA XL 42 CHAMELEON Sx 25 COUGAR Sx 25 MAGNUM XL 54 PREMIER Tx 36 CHAMELEON Tx 36 COUGAR Tx 36 CRYSTAL Tx 40 CHROMA Tx 40 CHAMELEON PREMIER 36 CHAMELEON 36 CHAMELEON 25 COUGAR 36 COUGAR 25 Recommended S
p
are Part
Tension Spring for Vertical Alignment Arm 6775A264R01 x x x x x x x x x
Tension Spring for Cameral Alignment 6775A252R01 xxxx x x x x x x x xxxx
Tension Spring for Camera Base Plate 6775A253R01 xxxxxx x x x x x x x xxxx
9. Stand
Base, 40" 2205D702R01 x x x x x x x x
Base, 25" 2205D706R01 x x
Top Bar, 40" 2205D703R01 xxxx x x x x x x x x
Top Bar, 25" 2205D707R01 x x x x
Left Foot, small 2205D716R01 xxxxxx
Right Foot, small 2205D717R01 xxxxxx
Connect Tube, 25" 2205D719R01 x x
Connect Tube, 40" 2205D718R01 xxxx
Left Foot 2205D710R01 x
Right Foot 2205D711R01 x
Connect Tube, 54" 2205D712R01 x
Top Bar, 54" 2205D713R01 x
Left Leg 2205A716R01 xxxxxx x x x x x x x xxxx
Right Leg 2205A717R01 xxxxxx x x x x x x x xxxx
Collection Basket, Complete, 40" 2205D705R01 xxxx x x x x x x x x
Collection Basket, Complete, 25" 2205D709R01 x x x x
Collection Basket, Complete, 54" 2205D128R01 x
Castor w/o Brake for Scanner Bogie 2205A109R01 xxxxxx x x x x x x x xxxx
Castor with Brake for Scanner Bogie 2205A110R01 xxxxxx x x x x x x x xxxx
Fixing Screw for Scanner 2205A211R01 xxxxxx x x x x x x x xxxx
10. Receiving Table
Height Adjustment Screw 2205A137R01 xxxx x x x x x x x x
11. Scanner Accessories
AT-to-SCSI Host Adapter for PCI Bus 0090B019R01 x x x x x x x x
SCSI Cable, HD50/HD50, 3 m 0090B044R01 x x x x x x x x
USB Cable, 3 m 0090B051R01 x xxxx
USB Cable with Ferrite 6799D172R01 xxxxxx
IEEE 1394 Controller Board (Fire Wire) 0090B056R01 xxxxxx x x x x x x
IEEE 1394 Cable with Ferrite 6799D140R01 xxxxxx x x x x x x
12. Service Accessories
Optical Adjustment Pattern, 40", 2 Cam. 6779D107R01 x x x x
Optical Adjustment Pattern, 25", 1 Cam. 6779D105R01 x x x x x
Optical Adjustment Pattern, 40", 3 Cam. 6779D102R01 x x x
Optical Adjustment Pattern, 42", 3 Cam. 6779D134R01 xxxx x
Optical Adjustment Pattern, 36", 2 Cam. 6779D127R01 x x x x
Optical Adjustment Pattern, 54", 4 Cam. 6779D130R01 x x
Focus Pattern, 40" 6779D216R01 xxxx x x x x x x x x x
Focus Pattern, 25" 6779D215R01 x x x x x
Focus Pattern, 54" 6779D228R01 x x
SM Calibration Sheet, 40", packed 6799D116 x x x x x x x x x
SM Calibration Sheet, 42", packed 6799D171 xxxx x
SM Calibration Sheet, 25", packed 6799D115 x x x x x
SM Calibration Sheet, 54", packed 6799D165 x x
Adjustment Tools for Roller Sensor (2 pcs) 6779D133R01 xxxx x x
Adjustment Tools for Top Position Sensor (2 pcs) 6779D246R01 xxxx x x
