Contex COUGAR 36 - Fig. 3-6 CBF Component Layout

FSG/MTM/001 060511
41
Fig. 3-6 CBF Component Layout
+12V +1/-0V
IC1101,pin19
Camera
Motor
Output
GND
J901
pin1,3,5,7,9
+2.5V ±0.1V
C905,top
+5.0V
±0.2V
C913,bottom
+5.0V ±0.2V
C917,left
+5.3V +0/-0.2V
C918,bottom
+5.0V ±0.2V
C921,bottom
+3.3V
±0.1V
C901,bottom
+11.6V ±0.6V
Q102, bottom
