Contex COUGAR 36 - Fig. 3-14 SKDA Component Layout

FSG/MTM/001 060511
56
Wait LED
Yellow
Ready LED
Red/Green
Diagnostics LED
Red
Scanner ID Switch
Bottom View
Power LED
Red/Green
Power
Forward
Stop/Reverse
Appl. 1
Appl. 2
Appl. 3
GND
3.3V
J2,pin3
Top View
Switch 8
Switch 1
5.1V
C1,top
ON <-> OFF
Fig. 3-14 SKDA Component Layout
