Contex COUGAR 36 - Fuses; Markings; Jumper Settings; Hints

FSG/MTM/001 060511
32
3.4.6 Fuses
The type and rating of the fuse on the LMEA-Board is:
F1: T2.0AH/250V, type IEC 127- 2/5, UL R/C
CAUTION:
For continued protection against risk of fire, replace only with same type and rating of fuse.
3.4.7 Markings
COUGAR 25
LMEAdd
COUGAR 36
LMEAdd
CHAMELEON 25
LMEAdd
CHAMELEON 36
LMEAdd
CHAMELEON PREMIER 36
LMEAdd
CHROMA Tx 40
LMEAdd
CRYSTAL Tx 40
LMEAdd
MAGNUM XL 54
LMEAdd
COUGAR Tx 36
LMEAdd
CHAMELEON Tx 36
LMEAdd
PREMIER Tx 36
LMEAdd
where dd = board revision number.
3.4.8 Jumper Settings
Jumper: SR1
pos: A
3.4.9 Hints
Jumper on SR1: pos. A: Lamp controlled by SUC
pos. B: Lamp constant ON
No jumper: Lamp constant OFF
Control signals on J11:
pin 2: Lamp ON/OFF, LOW = ON
pin 8: Feed-Motor Step Pulse
pin 11: Feed-Motor Direction, LOW = FORWARD
Fan Speed Control:
A NTC Temperature Sensor located under the End Cover at the Operator Panel end of the
scanner controls the speed of the fan connected to J7.
