Contex COUGAR 36 - Camera Adjustment Wizard; Check and Adjustment of Focus

FSG/MTM/001 060511
94
4.2.3 Camera Adjustment Wizard
The Camera Wizard provides a guide for a complete adjustment of all cameras of the actual
scanner, that is, the adjustments described in the following sections 4.2.5 through 4.2.7.
Just start SCANtest 6, Test 27 and follow the instructions given by the Wizard.
4.2.4 Check and Adjustment of Focus
Images of the Focus adjustments are shown in:
Fig. 4-15 COUGAR 25, CHAMELEON 25, Focus Signals, page 96
Fig. 4-16 COUGAR 36, CHAMELEON 36, PREMIER 36, Focus Signals, page 96
Fig. 4-17 CHROMA Tx 40, CRYSTAL Tx 40, Focus Signals, page 97
Fig. 4-18 MAGNUM XL 54, Focus Signals, page 97
Fig. 4-19 COUGAR Tx 36, CHAMELEON Tx 36, PREMIER Tx 36, Focus Signals,
page 98
Adjustment Procedure
Do not loosen the camera. The construction of the camera ensures that the optical axis of the
lens is perpendicular to the scanning area and hence no alignment of the camera housing is
necessary.
Always perform the Focus adjustment before adjusting the Scan-Width, see “Interaction”
below.
Start SCANtest 6
Select Test 9
Select Corrected Light Profile*)
Press Execute
*) Note: If the camera is completely out of adjustment it may not be possible to run
Test 9 in ‘Corrected’ mode. In that case, select ‘Uncorrected’ and with the Optical
Adjustment Pattern placed in the scan-area make a coarse adjustment of Focus and
Scan-Width before continuing.
Select Blue (Default)
Select Detail View: Light Profile
Insert the Focus Pattern and feed it by using the Forward Key until the image of the pattern
with the resolution as shown below is seen on the upper image on the screen:
Model Focus
Pattern
Resolutio
n
COUGAR 25, CHAMELEON 25 6779D215 3.3 lp/mm
COUGAR 36, CHAMELEON 36,
CHAMELEON PREMIER 36,
6779D216 3.3 lp/mm
