FSG/MTM/001 060511
16
IEEE 1394 Controller (FireWire)
SCSI Controller
for IEEE 1394 interface respectively SCSI interface.
In order to stitch (bring together) the scanlines from adjacent cameras, the fields of vision of
the CCD-Cameras overlap slightly and a thin, black wire placed within the overlapped fields
of vision marks the virtual end, respectively start, of adjacent scanlines.
The scanlines from the individual cameras are mechanically aligned (by means of a small
electric motor) in the vertical direction. The Vertical Alignment and the Horizontal Stitching
may be done automatically by means of either SCANtest 6, Test 11 or as part the Scanner
Maintenance calibration procedure.
2.5 COUGAR Tx 36, CHAMELEON Tx 36, PREMIER Tx 36
The Block Diagram is shown in:
Fig. 2-7 COUGAR Tx 36, CHAMELEON Tx 36 and PREMIER Tx 36 Block Diagram,
page 24
The Tx 36 scanner range consists of:
Model: GK67D GL67D GM67D
Trade name:
COUGAR Tx 36 CHAMELEON Tx 36 PREMIER Tx 36
No. of cameras:
2 2 2
Chassis:
40 inches 40 inches 40 inches
Scan width:
36 inches 36 inches 36 inches
Scanner Controller:
SUCB SUCC SUCG
Computer
interface:
IEEE 1394/SCSI
(IMDA)
IEEE 1394/SCSI
(IMDA)
IEEE 1394/SCSI
(IMDA)
Scan mode:
Color
Monochrome
Color
Monochrome
Monochrome
Optical resolution:
400 dpi 400 dpi 400 dpi
Each of the three models GK67D, GL67D, and GM67D are marketed with two different
levels of functionality, such as image resolution, scanning speed, scanning modes, etc:
Model: GK67D (IEEE 1394 and SCSI interface)
Trade names: COUGAR Tx 36 (basic level of functionality)
COUGAR Tx 36 PLUS (enhanced level of functionality)
Model: GL67D (IEEE 1394 and SCSI interface)
Trade names: CHAMELEON Tx 36 (basic level of functionality)
CHAMELEON Tx 36 PLUS (enhanced level of functionality)
Model: GM67D (IEEE 1394 and SCSI interface)
Trade names: PREMIER Tx 36 (basic level of functionality)
PREMIER Tx 36 PLUS (enhanced level of functionality)
The basic versions of the scanners (COUGAR Tx 36, CHAMELEON Tx 36, and PREMIER
Tx 36) may be field upgraded to the enhanced versions (COUGAR Tx 36 PLUS,
