Contex COUGAR 36 - Page 129

FSG/MTM/001 060511
125
Fig. 4-48 Optical Adjustment Pattern, 3 Camera, 40”
CAMERA B
Scan-Width Patterns
Vertical Position Patterns
Focus Pattern (used for coarse Focus adjustment)
Sub-pattern A:
Sub-pattern B:
Sub-pattern C:
Detail A-A
ABC
CA ME RA C CAMERA A
