Control of Camera Motor
The Camera Motor for Vertical Alignment is driven from a controller IC on the CBE-Board.
The supply voltage for the motor is +12 V.
After replacement of CBE-Board, do:
• CCD-Centering, Section 4.2.6, page 109.
• Vertical Positioning, Section 4.2.7, page 110.
• Check Scan-Width, if it is within the limits given in Section 4.2.5, page 99, Focus will also
be OK, and no further adjustments are required.
• Run Scanner Maintenance, Section 6.1.7, page 142.
These adjustments can be made without loosening the Camera Fixing Screws and
without loosening the Focus Lock Ring / Lock Screw.
