6-6 996-0255 rev. b
Precision II Operation and Maintenance Manual
Electronics & Supplies
Part Number Description Quantity
504-3100 Marx PCB, 750V 1
504-3200 Power board, 750V 1
601-7200 PCB crystal oven 1
504-4400 Logic PCB, PU610C series 1
425-0013 24V power supply 1
421-0008 CB630C & CB631C trig. trans. 1
421-0042 CB632C & CB634C trig. trans. 1
504-6400 CB simmer PCB 1
504-4200 Assy, PCB PU630C pwr. brd. 1
313-0099 DI filter 1
Optics/Electro-optics
(refer to drawing p. 3-1)
Part Number Description Quantity
rep rate dependent
- consult factory
for part
Rear mirror 1
rep rate dependent
- consult factory
for part
Output coupler,
Gaussian
1
105-0022 Dichroics, 532nm 2
105-0023 Dichroics, 355nm 2
199-0116 Polarizer, plate 1
202-0001 Pockels cell 1
617-8000 SHG crystal 1
617-8020 THG, crystal 1
parts list end
