Continuum Precision II Series User Manual

Chapter III –Subassemblies
3-23
C
996-0255 rev. b
D. Electronics cabinet
Continuum’s electronics cabinets have a number of PC boards and electri-
cal plugs built into the chassis. Below is a drawing showing the built-in
features of the rack. On the next page is a drawing depicting the wiring
between the rack mounted modules.
Built-in rack
electronics.
Rear view
wall plug
cord
power
switch
Front view
CU (1 phase)
CB (1 phase)
CG (1 phase)
PU (3 phase)
ac filter box
DI water
CB head
cable
tap water
24 V power supply
switch for I/O panel
& fuses
