Precision II Operation and Maintenance Manual
C
2-16
996-0255 rev. b
022H PARAMETER DECREMENT
032H PARAMETER SELECT
042H RESET
013H SHUTTER
023H REMOTE/LOCAL
033H CHARGE
043H FIRE
014H Q-SWITCH ON/OFF
024H AUTO/MANUAL
034H START
044H STOP
015H HARMONIC GENERATOR #1 CW
025H HARMONIC GENERATOR #1 CCW
035H HARMONIC GENERATOR #2 CW
045H HARMONIC GENERATOR #2 CCW
There are two special command bytes that are sent back to the host com-
puter and allow it to see the status of the CU601C. The first command is:
Command (hex) Command Description
003H RETURNS PROGRAM
STATUS
When this command is sent to the CU601C, it sends back active program
status in six ASCII strings separated by a line feed and a carriage return.
The program parameter "ACTIVE PARAMETER" listed below refers to
parameter in which the laser is operating at any given time. If there are 2
PU's with the laser, then "LAST PU" refers to PU2. "MODE" refers to
remote or local mode. The six strings are returned in the following for-
mat:
Program Parameter String Format
REP RATE 4 BYTES+CR+LF
Q-SWITCH DELAY 4 BYTES+CR+LF
PULSE DIVISION 4 BYTES+CR+LF
SHOT COUNT 8 BYTES+CR+LF
BAUD RATE 5 BYTES+CR+LF
ACTIVE PARAMETER 1 BYTE +CR+LF
LAST PU 1 BYTE+CR+LF
MODE 1 BYTE+CR+LF
The other special command is:
Command (hex) Command Description
004H RETURNS CU601C
STATUS
