Chapter III – Subassemblies
3-31
C
996-0255 rev. b
HARMONIC GENERATOR #2 CW
HARMONIC GENERATOR #2 CCW
REMOTE/LOCAL
b) AUTO/MANUAL
This key toggles the CU601C between the auto and the
manual mode. Initially, the CU601C is in the manual
mode and the following is displayed:
When this key is pressed, the CU601C is placed into the auto mode. The
display will read:
The charge, parameter select, parameter increment, parameter decrement,
and remote/local keys are deactivated in this mode and all of the remain-
ing keys are active:
AUTO/MANUAL
START
STOP
FIRE
SHUTTER
RESET
PROGRAM INC
PROGRAM DEC
STORE
ACTIVATE
HARMONIC GENERATOR #1 CW
HARMONIC GENERATOR #1 CCW
HARMONIC GENERATOR #2 CW
HARMONIC GENERATOR #2 CCW
c) CHARGE
When in the manual mode, pressing this key causes a
charge command to be issued to the power units. The
charge LED lights up during the charging process and
will turn off when an “end of charge” signal is received
from all power units, resulting with the “end of charge”
LED being on. The capacitor banks are now fully charged.
If a charge signal is not received from all of the power
units, then an “end of charge” failure will occur. The 1st
line of the display will show the following:
MANUAL MODE
SHOT COUNT XXXXXXX
FLASH ONLY PGM1
xxHz xuS ACTIVE
