Control Techniques Mentor MP User Manual

Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Menu 12
Mentor MP Advanced User Guide 163
Issue Number: 4 www.controltechniques.com
12.10 Variable selector 1 mode
12.30 Variable selector 2 mode
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 10
Default 0
Update rate 4 ms x number of menu 9 or 12 functions active read
12.11 Variable selector 1 destination
12.31 Variable selector 2 destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 0.00 to Pr 22.99
Default Pr 0.00
Update rate Read on reset
12.12 Variable selector 1 output
12.32 Variable selector 2 output
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21 1 1
Range ±100.00 %
Update rate 4 ms x number of menu 9 or 12 functions active write
12.13 Variable selector 1 source 1 scaling
12.33 Variable selector 2 source 1 scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range ±4.000
Default 1.000
Update rate 4 ms x number of menu 9 or 12 functions active read
12.14 Variable selector 1 source 2 scaling
12.34 Variable selector 2 source 2 scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range ±4.000
Default 1.000
Update rate 4 ms x number of menu 9 or 12 functions active read
