Control Techniques Mentor MP User Manual

Menu 4
Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
66 Mentor MP Advanced User Guide
www.controltechniques.com Issue Number: 4
The current demand filter filter is defined by this parameter if the speed gain select (Pr 3.16) is one.
The maximum for Pr 4.08 and Pr 4.20 is defined by this parameter
Sets a threshold value of speed feedback, beyond which Pr 4.31 changes to 1 to indicate that the threshold has been exceeded, and is the starting
point for taper 1. The current limit reduces, as a function of speed, to an end point defined by Pr 4.29.
The output of the taper block controls Pr 4.18.
If only 1 taper is used, it must be Taper 1. If both are used, Taper 1 must be first. Refer to the diagrams under Pr 4.32.
Sets a threshold value of speed feedback, beyond which Pr 4.32 changes to 1 to indicate that the threshold has been exceeded, and is the starting
point for taper 2. The current limit reduces, as a function of speed, to an end point defined by Pr 4.30.
The output of the taper block controls Pr 4.18.
If only 1 taper is used, it must be Taper 1. If both are used, Taper 1 must be first. Refer to the diagrams under Pr 4.32.
Defines the current at the end of taper 1.
4.23 Current demand filter 2
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0.0 to 25.0 ms
Default 6.0
Update rate Background read
4.24 User current maximum scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 111
Range 0.0 to TORQUE_PROD_CURRENT_MAX %
Default 150.0
Update rate Background read
4.27 Current taper 1 threshold
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 111
Range 0.0 to 10,000.0 rpm
Default 10,000 rpm
Update rate Background read
4.28 Current taper 2 threshold
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 111
Range 0.0 to 10,000 rpm
Default 10,000 rpm
Update rate Background read
4.29 Current taper 1 end point
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0 to 1000.0 %
Default 1000.0 %
Update rate Background read
