Manuale di Istruzione
Instruction Manual
23/08/2018 Rev.1 EN
100
6. Adjust the load rate by acting on the flow control valve knob;
Fig. 5-18
7. Once the load cell is under load, a moderate speed should be used, making
adjustments with the flow control valve knob as described above. By taking the load
rate close to zero it is possible to stop the load increase and maintain an almost
constant pressure. The value of the applied load is updated in real time on the
display;
8. To interrupt the load, turn OFF the pump motor switch and turn lever B slowly back
and lever A down to discharge the oil pressure;
Fig. 5-19
9. Make at least 3 load-unload cycles, arriving at the full scale of the load sensor
connected to the WIZARD 2, so as to stabilize the signals. After this, proceed with
the check and compare the values shown by the WIZARD 2 with those of the
reference load cell;
