5
318832000
Table 1. Design Data (cont’d)
50 HZ Unit:
1/3 HP refrigeration 230V, 50 HZ (Requires a Remote Carbonator)
Four Flavor 497354XXX
Five Flavor 497355XXX
497400XXX
498355XXX
498400XXX
Six Flavor 497356XXX
497401XXX
498356XXX
1/4 HP refrigeration 230V 50 Hz w/built-in Carbonator
Four Flavor 497404XXX
Five Flavor 497405XXX
Six Flavor 497416XXX
NONCARBONATED CARBONATED UNITS:
60 HZ Unit:
1/3 HP refrigeration 115 V, 60 HZ
Five Flavor 412155XXX
412165XXX
Six Flavor 412156XXX
412166XXX
Overall Dimensions:
Width 16 1/4 inches
Height 27 5/8 inches
Depth 24 1/2 inches
Weight: Four, Five or Six-Flavor Standard and NonCarbonated Unit with
1/3 HP refrigeration.
Shipping (one carton) approx. 124 Pounds
Dry Weight (approx.) 115 Pounds
Ice Bank Weight 31 Pounds
Drop in Refrigeration Assembly 58 Pounds
Weight: Four, Five, or Six Flavor Unit with 1/4 HP refrigeration and built-in
cold carbonator.
Shipping (one carton) approx. 130 Pounds
Dry Weight (approx.) 125 Pounds
Ice Bank Weight 24 Pounds
Drop in Refrigeration Ass’y 71.6 Pounds
Water Tank Capacity (no ice bank approximate)
Four, Five, or Six-Flavor 9 3/4 Gallons
1/3 H.P. Refrigeration Ass’y
Standard Unit 1/3 HP Refrigeration Five, or Six-Flavor Unit with built-in
Cold Carbonator and 1/4 HP Refrigeration
9 1/4 Gallons
Refrigerant Requirement See Unit
Nameplate
Ambient Operating Temperature 40° F to 100° F
