Cornelius VENTURE - Carbonator Water Pump Yearly Maintenance or after Water System Disruptions; Figure 9. Water Tank

3
1
8
8
3
2
0
0
0
3
2
CARBONATOR
SENSOR LEADS
FIGURE 9. WATER TANK (UNIT WITH BUILT-IN COLD CARBONATOR SHOWN)
12. Remove plug from drop-in refrigeration assembly platform water fill hole.
13. Fill water tank with clean water to top of stainless steel coils located in coil basket. USE LOW-MINERAL-
CONTENT WATER WHERE A LOCAL WATER PROBLEM EXISTS.
14. Install access plug in water fill hole.
15. Install hood on Unit by reversing removal procedure.
16. Install Unit front access panel by reversing removal procedure.
17. Plug Unit power cord into electrical outlet.
CARBONATOR WATER PUMP YEARLY MAINTENANCE OR AFTER WATER
SYSTEM DISRUPTIONS
WARNING: The carbonator water pump water inlet strainer screen and double liquid check
valve must be inspected and cleaned at least once a year under normal circumstances, and
after any disruptions (plumbing work, earthquake, etc.) to the water supply system that
might cause turbulent (erratic) flow of water through the system. A carbonator water pump with no
screen or a defective screen in the strainer would allow foreign particles to foul the double liquid
check valve. CO
2
gas could then back flow into the water system and create a health hazard.
